Filament extruder

Desktop Pellet Filament Extruder, Production Line

Desktop pellet filament extruder

https://www.researchgate.net/publication/343401328_The_3D-Printed_Bilayer's_Bioactive-Biomaterials_Scaffold_for_Full-Thickness_Articular_Cartilage_Defects_Treatment

More than 5pcs can make OEM.
Manual of Extruder Line II
Main Difference between Model A, B and C.

1, Extrude Speed:
A,B:300-650mm/min;
C:1800-2500mm/min
2, Adapt Materials,
A,B:Nylon,PLA ,ABS, PVA,PVA,PP,PS and wood-plastic etc.
C:Nylon,PLA ,ABS, PVA,PVA,PP,PS and wood-plastic etc.(Normal Temperature type),PEEK, PEI etc (High temperature more)
3, Working temperature
A: 220-300℃
B: Below 300℃
C: Below 320℃(max 600℃ need customizing)
4, Power
A,B:150W
C:240W
5, Biggest size of the applied particle
A,B:3-4mm
C:6-7mm

PARAMETERS:
1. Extrude Speed: 300mm/min~650mm/min
2. Diameter: 1.75mm and 3.00mm( 2 nozzles)
3. Adapt material: PLA ,ABS, PVA and wood-plastic etc.
4. Working temperature: below 300℃
5. Temperature control accuracy: +/- 1 ℃
6. Power: 150W
7. Power Supply:220V AC,50 or 60Hz(110VAC,50Hz to be customized)
8. Size: 502x135x252(mm)

RobotDigg Wellzoom Extruder
FEATURES:
1. Simple and beautiful appearance
2. Multiple protection to ensure that equipment work with high reliability
3. Easy to operate
4. Special screw, high-efficiency extrusion
5. Easy to clean the material cavity and change the nozzle.
6. Able to meet most of the thermoplastic materials.
7. Able to color. It can meet your needs about the color and material of filament.
8. Air-cooling + self-weight traction, making it more convenient and efficient.

Wellzoom Desktop pellet filament extruder(B)
A type improved, low power consumption, with speed control function
PARAMETERS:
SIZE:502x135x252(mm)
EXTRUSION SPEED:300~650mm/min
TEMPERATURE RANGE:below 300℃
POWER SUPPLY:220V 50Hz(Customizable 110V 50Hz)
POWER:150W

Desktop 3D Printing Filament Extrusion Line
Desktop extruder line is a tiny 3D supplies extrusion production line, it has a complete process that includes turning pellets into filaments, water-cooling and winding.
The desktop extruder is specifically designed for non-professional operators, especially for laboratories. The design is based on a simple concept. A simple operation panel can reduce the risk of misoperation; a well-designed structure can effectively avoid scalding operators.
If you want to produce new composite material for experiments or produce in small quantities, a Desktop extruder production line would be an ideal choice.
Desktop extruder lines include Wellzoom C extruder, water-cooling tractor, and auto winder.
Parameters:
Extrude Rate: 1800mm–2500mm/min
Adapt material:Nylon,PLA ,ABS, PVA,PVA,PP,PS and wood-plastic etc.
Working temperature: below 320℃(max 450℃ need customizing)
Temperature zones: Two temperature zones (Independent Control)
Accuracy of PID: +/- 1℃
Accuracy of filament: 1.75mm,+/-0.05; 3mm,+/-0.1
Power:240W
Power requirement: 220V,50Hz or 110V,50Hz
Diameter: 1.75mm and 3.00mm( 2 nozzles)

Desktop pellet filament extruder(C)
1. Simple appearance, easy to operate,
2. Easy to clean the material cavity and change the nozzle.
3. Special screw, high-efficiency extrusion
4. Able to meet most of the thermoplastic materials.
5. Able to modulate color. It can meet your needs about the color and material of filament.
6. Large-capacity hopper is transparent, you can easily monitor and add material
7. Dual-zone & independent temperature control can meet the requirement better for the composite material. Preheat zone is for melting materials. The extrusion zone is for controlling extrusion temperature.

Water-cooling tractor
1. The use of a stepping motor, with a stable traction speed
2. Stepless speed
3. The water-cooling or forced air cooling (forced air cooling module needs to be purchased separately) can be selected.

Auto winder
1. Own control technique, use photoelectric switches to detect position.
2. Automatically match the extrusion speed of the extruder.
3. The arranging mechanism can arrange the filament in order.
Pellet Extrusion Line 1st Generation
pellet extrusion line

Extruder Line II

Water-cooling tractor applied.

After more than two years, on the basis of the original product, we have made a deep improvement. The second-generation products - Desktop Extruder Line II were invented. They have the following advantages:
1.On-line measurement function. It provides a low-cost detection method to control the diameter of the filament.
2.Redesigned auto winder. It’s more simple and reliable.
3.A variety of cooling combinations(can be chosen). Such as double sink cooling, forced air cooling & water cooling combination, air cooling, low-temperature water cooling (15℃ below room temperature). They can adapt to different kinds of materials.

Water-cooling Tractor
Water-cooling tractor
1. Stepping motor is used to ensure stable traction speed.
2. Stepless speed control.
3. On-line measurement function.
4. A variety of cooling combinations can be chosen. We can provide the best solution.

Extruder Line II+ 450℃

Maximum extrusion speed: 4000mm / min(1.75mm, ABS)
Suitable materials: ABS, PLA, Nylon, wood plastic, PVA, PS, PEEK and so on
Solution of small batch production of PEEK 3D printing filament
Operating temperature: below 450℃
Temperature zone: 2 temperature zones (independent control)
Temperature control accuracy: ± 1℃
Accuracy of filament: 1.75mm, + / – 0.05; 3mm, + / – 0.1
Power requirement: 220V, 50Hz (110V, 50Hz need customizing)
Power: 220W-440W
Nozzle: 2 nozzles for 1.75mm and 3mm 3D Printing Filament(1.8mm, 3.2mm)

20mm extrude screw Extruder Line III
Wellzoom

II Tractor n Winder
Filament tractor and winder
III Tractor n Winder
Metering tractor and dual winder

You may also like...

Sours: https://www.robotdigg.com/product/1029/Desktop-Pellet-Filament-Extruder,-Production-Line

Noztek Pro Filament Extruder

Skip to content

Professional Desktop Pellet & Powder Filament Extruder for 3D Printing

SKU: PROCategory: Extruders

Description

About

The Noztek Pro Desktop Filament Extruder, based on the original design to solve the problem of expensive 3d printing filament. We wanted to give makers the opportunity and flexibility to create filament of their own spec. The current model has been constantly improved over the last 5 years, remaining a reputable classic today.

The Noztek Pro combines a high torque planetary motor and a bespoke engineered screw, offering fast extrusion of just about any polymer in pellet or powdered form. The Noztek Pro is a plug and play extruder, which means in just 15 minutes it can be unboxed and ready to use. Just plug in, turn on the heater and add the resin, then turn on the motor and you will be extruding straight away. With no kit to assemble, this extruder is extremely reliable simple and easy to use.

Noztek Pro Side View



Use & Efficiency

The Noztek Pro will extrude at 2.5m per minute, depending on the type of material you are extruding. This will result in 1Kg of filament in around 2 hours.
We now provide a pre-heater band as standard which takes most of the strain off the motor; improving the extrusion rate and increasing longevity.

Noztek Pro Filamentt Extruder 3/4 back base

This advanced extruder has been tested using an extensive range of polymers including ABS, PLA , PET. PP, HDPE, PP and many more.  Powdered resins, composite combinations and recycled plastic powders can be extruded thanks to our bespoke in-house manufactured screw design.  In fact, it’s capable of extruding just about anything you throw at it. You can also mix and make your own coloured filament, using readily available masterbatch pellets. These are simply mixed in the hopper, which opens up a whole new range of colour options.



NEW

The Noztek Pro is now available with an upgraded Stainless Steel Barrel & Screw, specially designed for durability while extruding abrasive materials.





Upgrade and extend your Extruding system with our Resin & Spool Dehydrator, Winder and Tolerance Puller

Noztek Pro Desktop Filament Extruder side view

Noztek  Pro Desktop Filament Extruder Specifications

  • Extrudes at 1-300°C

  • Bespoke screw design

  • Swappable barrel

  • *NEW* Stainless Steel Barrel & Screw option available
  • Filament tolerances 1.75mm (+ .04/ – .04)

  • 1.75 and 3mm dies are included, blanks are also available

  • 45° bracket included

  • Extrudes at up to 2.5m per minute

  • Fully assembled and ready to make filament straight out of the box

  • The diameter of the screw is 14mm width, with a 23° pitch, a 5mm depth and 5mm channel width and 26cm length.



All Noztek Extruders come with a full 1 year return to base Warranty

For UK customers we will ship a 220v unit. If you are ordering from overseas please let us know the voltage and frequency required, as we also keep 110v units in stock.

Noztek Pro Desktop Filament Extruder Kit Includes: 1 Fully assembled Filament Extruder, 0.5 kg ABS Pellets (MFI-22) (to get started right away), 2 dies (1.75mm and 3mm), 1 instruction manual.

New stainless steel barrel screw and coupling for pharma and abrasive material use.



click here for the user manual
